What is the structure of Metso HP series cone crusher?

2. Lubrication and Hydraulic System: The lubrication and hydraulic systems are integrated into a single housing.

Lubrication System: The lubrication assembly includes: air filter set, oil filter, directional valve, electric motor, float switch, pump, and cooler. 70% of the lubricating oil is used for crusher cooling, and 30% is used for lubrication.

Hydraulic series: The hydraulic system consists of a hydraulic tank (hydraulic pump, drilled block, pressure accumulator, pressure sensor, pressure gauge, filter), clamping cylinder assembly (to prevent the fixed cone from rotating and lifting the locking ring during ore breaking), tramp release cylinder (which can quickly and easily clear the cavity, and the same set of hydraulic cylinders can be used to achieve tracheal release and cavity clearing), a hydraulic motor (rotating the fixed cone, continuously and accurately adjusting the discharge port, and shortening maintenance time), pipelines and an operating box.
