CH870/H7800 refer to the cone crusher model by Sandvik.
Therefore, there is not a single "part number" for the entire crusher. Instead, there are thousands of part numbers for its individual components.
Here are some examples of critical parts for the CH870/H7800 crusher:
| BOTTOMSHELL ASSEMBLY | 452.0697-001 | SUPPORT RING | 452.0687-001 |
| WEARING PLATES, BOTTOMSHELL | 452.1191 | DOWEL PIN | 442.8290-01 |
| DUST COLLAR ASSEMBLY | 452.0998-901 | WEARING PLATE | 452.0710-901 |
| ECCENTRIC ASSEMBLY | 452.0809-901 | WASHER TRBSB 17X42 | 847.0060-00 |
| HYDROSET CYLINDER ASSEMBLY | 452.0953-901 | FEED HOPPER, LOWER | 452.0799-901 |
| PINION SHAFT HOUSING ASSEMBLY | 452.0656-901 | FEED HOPPER, UPPER | 452.0802-901 |
| MAIN SHAFT ASSEMBLY | 452.0917-901 | CONE EC | 452.1451-901 |
| TOP SHELL ASSEMBLY | 452.0684-901 | WEARING RUBBER | 452.1370-901 |
| FEED HOPPER | 452.0760-901 | LOCK NUT M16 8 FZB ISO 7040 | 845.0215-00 |
| HYDROSET SYSTEM | 452.1488-901 | SPLITTER | 452.1741-901 |
| HOSES AND PROTECTIONS AT CRUSHER | 452.1158-901 | COVER | 452.1455-901 |
| DIRECT DRIVE ON SUB-FRAME | 452.1157 | RUBBER SHEET | 452.1753-901 |
| V-BELT DRIVE ON SUB-FRAME | 452.0946 | WEARING RUBBER | 452.1296-001 |
| V-BELT DRIVE, FIXED | 452.1881 | RUBBER ATTACHMENT STRIP | 452.1303-001 |
| TOOL LIST | 452.1257 | CONE EC | 452.0792-901 |
| OVERPRESSURE INSTALLATION | 452.1084 | RUBBER SHEET EC | 452.1137-001 |
| BOTTOM SHELL | 452.0675-001 | RUBBER PLUG | 873.1287-00 |
| FOOT BASE | 452.1064-001 | ADJUSTING UNIT | 452.1431-901 |
| FOOT FOR SUBFRAME BASE | 452.0977-001 | SCREW M6S 20X65 8.8 FZB ISO 4017 | 840.0650-00 |
| FOOT FOR SUBFRAME, MIRROR - INVERTED BASE | 452.0977-002 | WASHER TBRSB 21X58 | 847.0197-00 |
| SCREW M6S 30X110 8.8 FZV ISO 4014 | 840.0693-00 | LOCK NUT M20 8 FZB ISO 7040 | 845.0203-00 |
| WASHER BRB 31X58 HB200 | 847.0125-00 | SCREW M6S 24X130 8.8 FZB 1SO 4017 | 840.1192-00 |
| BOSS | 442.7907-01 | DISTRIBUTION BOX | 452.1443-901 |
| COVER | 442.7201-00 | SCREW M6S 20X35 8.8 FZB LS0 4017 | 840.1135-00 |
| STUD WELD | 843.1578-00 | WEARING PLATE | 452.1447-001 |
| WASHER BRB13X24 FZB HB200 IS0 7089 | 847.0147-00 | RUBBER SHEET | 442.9747-01 |
| LOCK NUT M12 8 FZB ISO 7040 | 845.0030-00 | RUBBER SHEET | 442.9751-01 |
| LINER-PIN SHAFT ARM | 452.1066-901 | RUBBER SHEET | 442.9751-02 |
| LINER-NARROW ARM | 452.1065-901 | RUBBER SHEET | 442.9750-01 |
| BNED | 442.9396-00 | SCREW M6S 16X65 8.8 FZB ISO 4014 | 840.0071-00 |
| FLANGE | 900.2199-00 | MAIN VALVE | 902.0850-00 |
| SCREW M6S 16X50 8.8 FZB ISO 4017 | 840.0068-00 | PIPLT VALVE BLOCK | 902.0851-00 |
| WASHER BRB17X30HB200 FZB 1S07089 | 847.0016-00 | VALVE BLOCK | 452.0978-001 |
| O-RING | 873.0129-00 | REDUCING THREADED ADAPTER | 900.2291-00 |
| BOTTOM SHELL BUSHING | 452.0795-001 | MEASURING NIPPLE 1/4“ | 900.2292-00 |
| PIN CP 12M6X30 1S0 2338 | 853.0464-00 | ADAPTER G 3/3” BXG ½” B | 900.0647-00 |
| SWIVEL RUN TEE G 3/4 | 900.2127-00 | SEAL TREDO 18 | 873.0384-00 |
| COVER 3/4 | 900.0276-00 | RETURN OIL HOSE | 452.1616-901 |
| SEAL RING TREDO 20 3/4 | 873.0385-00 | HYDRAULIC HOSE | 452.1286-001 |
| WEARING PLATES, BOTTOMSHELL | 452.1191-901 | HYDRAULIC HOSE | 452.1287-001 |
| ECCENTRIC WEARING PLATE | 452.0808-001 | HYDRAULIC HOSE | 452.1288-001 |
| PIN | 853.0646-00 | ADAPTER | 900.2599-00 |
| WEARING PLATE | 452.1077-001 | STRAIGHT ADAPTER | 900.0659-00 |
| WEARING PLATE | 452.1078-001 | HYDRAULIC HOSE SAE 100 R2AT 2”X2000 | 452.1538-001 |
| WEARING PLATE | 452.1078-002 | BRACKET | 452.1414-001 |
| ROUND BAR 1312-00 D 20 L=100 | 803.0625-00 | RUBBER CLOTH | 452.1415-001 |
| PLATE HB 360-440 T=6 L=480 | 800.0518-00 | WEARING LINER | 452.1419-901 |
| DUST COLLAR | 452.0926-001 | BOLT | 442.9503-01 |
| SCREW M6S 16X30 8.8 FZB 1S0 4017 | 840.0064-00 | SUPPORT | 452.1425-901 |
| RING | 452.0999-001 | BRACKET | 452.1426-001 |
| SCREW M6S 16X60 8.8 FZB 1S0 4017 | 840.0070-00 | BRACKET | 452.1448-001 |
| WASHER BRB 17X30 HB200 IS07089 | 547.0016-00 | BRACKET | 452.1449-001 |
| LOCATING BAR | 452.0834-001 | BRACKET | 452.1468-901 |
| SHIM T=0,1 | 452.1279-001 | PROTECTION | 452.1427-001 |
| SHIM T=0,5 | 452.1279-002 | BRACKET | 452.1476-901 |
| SHIM T=0,7 | 452.1279-003 | SCREW M6S 12X60 8.8 FZB ISO 4014 | 840.0051-00 |
| SHIM T=1 | 452.1279-004 | SCREW M6S 12X50 8.8 FZB ISO 4014 | 840.0049-00 |
| SCREW MC6S 10X40 8.8 FZB | 841.0254-00 | HOSE SAE 100 R2AT 1”1200 | 452.1579-001 |
| GASKET | 452.1267-001 | SEAL RING TREDO 30 | 873.0390-00 |
| INNER DUST SEAL RING | 452.1000-001 | FLANGE HALFSAE 3000 2”PSI | 900.2592-00 |
| ECCENTRIC | 452.0540-001 | O RING | 873.0755-00 |
| ECCENTRIC BUSHING 32+37+42+47 | 452.0805-001 | SCREW MC6S 12X35 8.8 FZB | 841.0268-00 |
| ECCENTRIC BUSHING 47+52+57+62 | 452.0806-001 | HOSE SAE 100 RIAT 3/4”X1000 | 452.1580-001 |
| ECCENTRIC BUSHING 62+68+74+80 | 452.0807-001 | HOSE SAE100 RIAT 1”X1000 | 452.1587-001 |
| HUB | 452.0516-001 | PILOT VALVE PROTECTION | 452.1511-001 |
| RING | 452.0902-901 | SCREW M6S 16X40 8.8 FZB ISO 4017 | 840.0066-00 |
| SCREW M6S 16X50 8.8 FZB 1S0 4017 | 840.0069-00 | SCREW M6S 12X20 8.8 FZB ISO 4017 | 840.0622-00 |
| WASHER BRB 17X30 HB200 FZB ISO 7089 | 847.1106-00 | STRAIGHT HOSE COUPLING | 452.1536-901 |
| KEY | 442.9610-01 | SCREW MF6S 16X35 8.8 | 841.0578-00 |
| SCREW MC6S 16X90 12.9 | 841.0535-00 | BRACKET | 452.1414-002 |
| SCREW MC6S 16X55 12.9 | 841.0548-00 | HOSE | 819.0061-00 |
| WASHER B16 17X30 | 847.0181-00 | O RING | 873.0615-00 |
| GEAR AND PINION SET 50HZ | 452.0530-901 | END COVER 2” SAE-FLANGE | 452.1589-001 |
| GEAR AND PINION SET 60HZ | 452.0531-901 | END COVER 3/4” SAE-FLANGE | 452.1592-001 |
| KEY | 452.1063-001 | FLANGE HALF SAE 3000 3/4" | 900.2602-00 |
| HYDROSET CYLINDER | 452.0970-001 | FLANGE HALF SAE 3000 1” | 900.2385-00 |
| SCREW M6S 30X200 10.9 | 840.1176-00 | O RING | 873.1299-00 |
| WASHER BRB 31X56 HB305 1S0 7089 | 847.0310-00 | END COVER L”SAE-FLANGE | 452.1591-001 |
| HYDROSET CYLINDER BUSHING | 452.0969-001 | END COVER 4” SAE-FLANGE | 452.1590-001 |
| SCREW M6S 10X16 8.8 FZB ISO 4017 | 540.0032-00 | SCREW MC6S 10X35 8.8 FZB | 841.0253-00 |
| WASHER BRB 10,5X22 HB200 | 847.0144-00 | LOCK NUT M10 8 FZB SO 7040 | 845.0213-00 |
| O-RING 740X8,4 | 873.1247-00 | BRACKET FOR VALVE | 452.1602-901 |
| PISTON ASSEMBLY | 452.1049-901 | SPACER | 452.1665-001 |
| PIN CP 25M6X60 | 853.0119-00 | SUBFRAME DIRECT DRIVE | 452.0905-901 |
| PISTON WEARING PLATE | 452.0538-001 | DUST SEAL | 452.1642-901 |
| STEP WASHER | 452.0537-001 | PROTECTIVE CAP FOR SHAFT | 452.1014-901 |
| CHEVRON PACKING | 452.0986-901 | SHAFT COUPLING OMEGA E120 | 930.0313-00 |
| PACKING CLAMP PLATE | 452.0990-001 | RUBBER DAMPER | 442.9650-92 |
| SCREW MC6S 12X30 8.8 FZB | 841.0267-00 | SPACER WITH FLAT BAR | 452.1622-901 |
| HYDROSET CYLINDER COVER | 452.0972-001 | SUPPORT | 458.0452-01 |
| PROTECTION PLUG | 919.0190-00 | WASHER | 442.9342-01 |
| PLUG VSTI R ½”-ED | 900.2307-00 | SENSOR | 984.0217-00 |
| SCREW MC6S 8X40 8.8 FZB | 841.0239-00 | SHIM T=1 | 458.0406-01 |
| AIR BLEEDER VALVE | 902.0605-00 | SHIM T=0,5 | 458.0406-02 |
| 0-RING 629,3X5,7 | 873.1352-00 | SHIM T=0,3 | 458.0406-03 |
| O-RING 685X5,7 | 873.1351-00 | THREADED PIN M30X130 MACHINED | 452.1609-001 |
| PISTON SENSOR | 984.0421-00 | SCREW M6S 36X180 8.8 FZV ISO 4014 | 840.0718-00 |
| 0-RING 44,2X3 | 873.0111-00 | NUT M6M M30 8 FZV ISO 4032 | 845.0013-00 |
| PINION SHAFT HOUSING | 452.0657-001 | WASHER BRB 8.4X16 HB200 ISO 7089 | 847.0012-00 |
| SCREW M6S 24X100 8.8 FZV ISO 4014 | 840.0672-00 | SCREW M6S 8X20 8.8 FZB ISO 4017 | 840.0021-00 |
| WASHER TBRSB 26X65 | 847.0063-00 | SCREW M6S 20X50 8.8 FZB ISO 4017 | 840.0077-00 |
| GASKET T=0,5 | 442.9364-01 | SUBFRAME V-BELT DRIVE | 452.1263-901 |
| GASKET T=0,5 | 442.9364-02 | MOTORFRAME FOR V-BELT DRIVE | 452.1004-901 |
| GASKET T=0,5 | 442.9364-03 | SLIDE RAIL | 458.0773-01 |
| BEARING 32230 J2 | 868.0832-00 | BRACKET | 458.0156-00 |
| NUT KM 30 150X2S02982 | 845.0164-00 | COUPLING RB 2,15 D-110/120 | 930.0262-00 |
| LOCK WASHER MB 30 ISO 2982 | 847.0299-00 | SPACER | 458.0307-01 |
| WEAR RING | 442.9809-01 | SHAFT | 458.0348-01 |
| SPACER RING | 442.9808-01 | BEARING HOUSING | 458.0349-01 |
| O RING | 873.0136-00 | KEY T 28X16X110 | 857.0336-00 |
| OIL SEAL RING TYPE 4 | 873.1219-00 | SCREW SK622 16X40 | 842.0019-00 |
| BEARING COVER, INNER | 452.0716-001 | ROLLER BEARING 23024 | 868.0829-00 |
| BEARING COVER, OUTER | 442.9260-01 | CLAMPING SLEEVE H3024 | 868.0830-00 |
| SCREW M6S 12X35 8.8 FZB ISO 4017 | 840.0046-00 | SUPPORT BLOCK | 649.0168-01 |
| SCREW M6S 20X60 8.8 FZB ISO 4017 | 840.0078-00 | GUIDE RING | 871.0110-00 |
| WASHER BRB 21X36 HB200 | 847.0132-00 | FELT SEAL FS 460 | 873.1289-00 |
| GASKET T=0,8 | 442.9365-01 | V-RING V-110A | 873.0898-00 |
| GASKET T=0,8 | 442.9366-02 | COVER END | 871.0404-00 |
| SPRING PIN | 853.0590-00 | SPACER | 442.9343-01 |
| PINION SHAFT | 452.0727-001 | DRIVING | 452.1846-901 |
| PLUG | 900.2388-00 | V-BELT GUARD, SHAFT | 452.1297-901 |
| KEY | 857.0360-00 | V-BELT GUARD, ASSY | 452.0769-901 |
| KEY | 857.0354-00 | WASHER BRB 37X66 HB200 SO 7089 | 847.0162-00 |
| ELBOW 3/4 IS0 49 | 900.0022-00 | SCREW M6S 36X130 8.8 FZV ISO 4017 | 840.1038-00 |
| SCREW | 842.0020-00 | SCREW M6S 27X70 8.8 FZV ISO 4017 | 840.0669.00 |
| ADAPTER ¾” | 900.0655-00 | NUT M6M M12 8 FZB ISO 4032 | 845.0007-00 |
| OIL LEVEL GAUGE | 442.9346-01 | NUT M6M M36 8 FZV ISO 4032 | 845.0221-00 |
| SEAL RING TREDO 26 | 873.0387-00 | NUT M6M M36 8 FZV ISO 4032 | 840.0048-00 |
| ADAPTER G 1 B | 900.0656-00 | SCREW M6S 24X150 8.8 FZV ISO 4014 | 840.0677-00 |
| SEAL RING TREDO 23 | 873.0386-00 | LOCK NUT M24 8 FZB | 845.0216-00 |
| RETAINING RING | 855.0134-00 | V-BELT PULLEY 710 MGT 160 16XSPC | 879.0588-00 |
| SCREW M6S 16X120H | 840.1063-00 | V-BELT PULLEY 710 MGT 160 14X8V | 879.0577-00 |
| NUT M6M M16 8 FZB ISO 4032 | 845.0009-00 | BUSHING | 452.1884-901 |
| MAINSHAFT & HEAD CENTRE | 452.1930-301 | SUPPORT BLOCK | 649.0168-04 |
| MAIN SHAFT SLEEVE | 452.0505-001 | ADAPTER FIXED 7’ | 452.1848-901 |
| MAIN SHAFT STEP | 452.0507-001 | KEY R 28X16X140 | 857.0290-00 |
| RETAINING RING SGA 100 | 855.0026-00 | NUT M6M M24 8 ISO 4032 | 845.0012-00 |
| MANTLE A | 452.0837-001 | WASHER TBRB 40X68 | 847.0122-00 |
| MANTLE EF | 452.0845-001 | LIFTING TOOL | 452.1247-901 |
| HEAD NUT WITH BURNING RING | 452.0936-901 | LIFTING TOOL | 452.1246-901 |
| INNER HEAD NUT | 452.0930-001 | LIFTING TOOL | 442.9446-00 |
| BURNING RING | 452.0938-001 | LIFTING TOOL | 452.0452-001 |
| DUST SEAL RING | 452.0924-001 | PISTON STOP PLATE | 452.1512-901 |
| RETAINING RING | 452.0921-001 | SCREW M6S 30X100 | 840.0692-00 |
| RETAINER | 442.9367-01 | LOWERING ROD M16X900 | 442.7284-90 |
| SCRAPER | 452.1264-001 | LOWERING ROD M30X1000 | 843.1529-00 |
| SCREW M6S 16X70 8.8 FZB ISO 4014 | 840.0072-00 | EYE BOLT LT M80 | 899.0336-00 |
| TOP SHELL | 452.0664-00 | EYE BOLT LT M30 | 899.0032-00 |
| SCREW M6S 42X280 8.8 1S0 4014 | 840.1124-00 | EYE BOLT LT M24 | 899.0031-00 |
| NUT M6M M42 8 FZB ISO 4032 | 845.0322-00 | EYE BOLT LT M20 | 899.0160-00 |
| WASHER BRB 43X80 HB200 SS3576 | 847.0171-00 | EYE BOLT LT M16 | 899.0147-00 |
| WASHER HB 200 | 442.9979-01 | EYE BOLT LT M12 | 899.0155-00 |
| PROTECTIVE CAP | 899.0278-00 | EYE BOLT LT M10 | 899.0099-00 |
| SCREW M6S 42X120 8.8 FZB | 442.9530-03 | EYE BOLT LT M80 | 899.0244-00 |
| SCREW M6S 16X25 8.8 FZB 1S04017 | 840.0634-00 | RING SPANNER STRIKING 65MM | 920.0110-00 |
| ARM SHIELD | 452.1060-001 | RING SPANNER STRIKING 55MM | 920.0109-00 |
| LUBRICATION NIPPLE R1/4 | 914.0093-00 | RING SPANNER STRIKING 46MM | 920.0238-00 |
| PIPE BUSHING 3/4X1/4 ISO 49 | 900.0139-00 | U-RING SPANNER 55 MM | 920.0243-00 |
| STEEL PIPE | 808.0095-00 | U-RING SPANNER 46 MM | 920.0131-00 |
| COMPRESSION FITTINGS | 900.0435-00 | U-RING SPANNER 36 MM | 920.0135-00 |
| PLUG | 900.1132-00 | U-RING SPANNER 30 MM | 920.0134-00 |
| SPIDER CAP | 452.0553-001 | U-RING SPANNER 24 MM | 920.0022-00 |
| AIR FILTER | 912.0114-00 | U-RING SPANNER 18 MM | 920.0244-00 |
| NIPPLE | 900.0169-00 | U-RING SPANNER 16 MM | 920.0245-00 |
| ELBOW | 900.0002-00 | U-RING SPANNER 19 MM | 920.0042-00 |
| STEEL PIPE | 808.0220-00 | U-RING SPANNER 14 MM | 920.0040-00 |
| COMPRESSION FITTINGS | 900.0425-00 | U-RING SPANNER 10 MM | 920.0038-00 |
| O RING | 873.1210-00 | U-RING SPANNER 8 MM | 920.0037-00 |
| SCREW M6S 20X100 8.8 FZB ISO 4014 | 840.0653-00 | SOCKET SCREW KCY 5 | 920.0035-00 |
| SPIDER BUSHING | 452.1619-001 | SOCKET SCREW KEY 5/8" | 920.0032-00 |
| TEMPERATURE SENSOR | 191.2376-00 | CHUNK OF LEAD | 442.0800-91 |
| CONNECTION BOX | 191.2365-00 | FCELER GAUGE 0,05-1 MM | 923.0422-00 |
| ELBOW 1/4 ISO 49 | 900.0075-00 | OVER PRESSURE AGGR. | 452.1168 |
| SCREWM6S 20X90 8.8 FZB 1S0 4017 | 840.0652-00 | BUSHING 1 1/2 X 3/4 ISO 49 N4 | 900.0154-00 |
| SEAL RING | 452.1599-001 | HOSE COUPLING R 3/4 | 900.1424-00 |
| RING | 452.0550-001 | HOSE 1” | 819.0187-00 |
| RETAINING RING | 452.0549-001 | SOCKET RP 3/4 | 900.0275-00 |
| SCREW MC6S 6X45 8.8 FZB | 841.0225-00 | T-PIPE PLASTIC ¾ | 900.2572-00 |
| PLUG | 900.0981-00 | HOSE CLIP 28 SMS 2298 DY 23-27 MM | 900.1358-00 |
| CONCAVE EC | 452.0838-001 | OVER PRESSURE AGGR. 200 V 50 HZ | 452.1168-50/200 |
| CONCAVE EF | 452.0840-001 | OVER PRESSURE AGGR. 400 V 50 HZ, 460V 60HZ | 452.1168-50/400 |
| CONCAVE F | 452.0841-001 | OVER PRESSURE AGGR. 525 V 50 HZ | 452.1168-50/525 |
| CONCAVE MF | 452.0842-001 | OVCR PRESSURE AGGR. 550 V 50 HZ | 452.1168-50/550 |
| CONCAVE M | 452.1754-001 | OVER PRESSURE FAN | 442.9325-00 |
| SEALING COMPOUND | 873.1112-00 | AIR FILTER FK 200 | 912.0219-00 |
| FILLER RING EC | 452.0891-901 | MOTOR IEC 71-2 0.37KW IM3011 200V 50HZ | 972.0845-00 |
| FILLER RING EF, F, MF | 452.0898-901 | MOTOR IEC 71-2 0.37/0.43KW IM3011 400V 50HZ.460V,60HZ | 972.0838-00 |
| SCREW N6S 24X110 8.8 FZV ISO 4014 | 840.0673-00 | MOTOR IEC 71-2 0.37KW IM3011 525V 50HZ | 972.0843-00 |
| THREAD TRAY M24X3X1,5D | 899.0293-00 | MOTOR IEC 71-2 0.37KW IM3011 550V 50HZ | 972.0842-00 |
| WASHER BRB 25X45 HB200 | 847.0124-00 | LOCK NUT M36 8 FZB | 845.0273-00 |
| SCREW M6S 24X80 8.8 FZV ISO 4017 | 840.0670-00 | SLEEVE | 442.9353-01 |
| WEARING PLATE | 452.1369-901 | WASHER | 442.9354-01 |
| SCREW M6S 36X540 8.8 | 840.1136-00 | DISC SPRING | 863.0015-00 |
IPv6 Network Supported |
Sitemap |
XML |
Blog |
Privacy Policy
Our hours
Mon 11/21 - Wed 11/23: 9 AM - 8 PM
Thu 11/24: closed - Happy Thanksgiving!
Fri 11/25: 8 AM - 10 PM
Sat 11/26 - Sun 11/27: 10 AM - 9 PM
(all hours are Eastern Time)
