Replacement Crushing Parts HP Series Eccentric

Eccentric, which widely used in Metso, Nordberg HP series eccentric assembly. We also can provide other parts like socket assembly, main frame assy, countershaft assy, etc...

Item No :
HP100, HP200, HP300, HP400, HP500, HP700, HP800, HP900, HP3, HP4, HP5, HP6, MP800, MP1000, MP1250
Part Number :
ONA-1031136180, ONA-1031143420, ONA-7043358004, ONA-7043358008, ONA-1031143668, ONA-N43358015, ONA-N43358017, ONA-N43358030, ONA-N43358026, ONA-N43358027, ONA-N43358031, ONA-N43358028, ONA-7043358002, ONA-N43358025, ONA-7043358009, ONA-1031136156
Payment :
TT
Product Origin :
China
Color :
Customized
Shipping Port :
Shanghai
Lead Time :
Stock
Order(MOQ) :
1

Inquiry Now

Product categories

New products

Product Details

ONA China rock crusher parts eccentric, it is an essential component found in certain types of crushers, such as suit to Metso Nordberg gyratory crushers and cone crushers. The crusher wear parts mining eccentric is a mechanical device that is responsible for rotating the main shaft of the crusher. Its primary function is to convert the rotary motion generated by the electric motor into the crushing action of the crusher's mantle or cone liner.

The crushing cone crusher spare parts eccentric is typically mounted on the main shaft and secured with a series of bolts. As the eccentric rotates, it causes the main shaft to oscillate or gyrate, resulting in the compression and crushing of the material fed into the crusher chamber. The eccentric motion creates a "squeezing" action, which reduces larger rocks into smaller fragments suitable for further processing.

HP400 Eccentric
Suit to Metso Nordberg
Original Quailty
Technical Support

E.g. HP400 Eccentric Assy ONA-7090228301

No.	Part Number	Description	Quantity
1	ONA-1031136180	ECCENTRIC	1
2	ONA-1022074069	ECCENTRIC BUSHING	1
3	ONA-1057605169	THRUST BEARING, UPPER	1
4	ONA-1036803301	GEAR	1
5	ONA-1003766291	CAP SCRW HEXSCKTHD	6
6	ONA-1003086066	WASHER, LOCK	6
7	ONA-7001619336	PIN, PARALLEL	1
8	ONA-7001530424	SCREW, HEXAGONAL	6
9	ONA-MM0361376	THREADLOCKER	1
10	ONA-1095059960	LOCKING COMPOUND	1

Can you provide technical support?

Yes, ONA has more than 5 engineers who worked in original more than 10 years, we can provide technical support to the best of our ability. Here’s what I can do:

1. Answer Technical Questions: ONA can help with questions related to various technical topics, such as products repaire, replace, install, and more.

2. Troubleshooting Guidance: ONA can offer step-by-step guidance on troubleshooting common issues with devices, software, or systems.

3. Explain Concepts: ONA can explain technical concepts in simpler terms to help you understand better.

4. Provide Documentation and Resources: ONA can guide you to relevant documentation, tutorials, or resources that might help with your issue.

5. Safety and Compliance Advice: I can remind you of important safety and compliance considerations when working with technical equipment or software.

Hot Tags : metso cone crusher eccentric metso crusher parts eccentric metso nordberg crusher eccentric wholesale crusher spare parts coal crusher parts metso crusher spare parts

leave a message

Please share your part numbers with us, we will provide offer ASAP!
